Tacrolimus

Indication and administrations

It is used after allogenic organ transplant to reduce the activity of the patient's immune system and so the risk of organ rejection. It was first approved by the FDA in 1994 for use in liver transplantation, this has been extended to include kidney, heart, small bowel, pancreas, lung, trachea, skin, cornea, and limb transplants. It has also been used in a topical preparation in the treatment of severe atopic dermatitis.

Pharmacodynamics

Tacrolimus was absorbed topically by intact skin at rates of 3.1, 4.9 and 6.8 ng/cm2 per hour, for the 0.03%, 0.1% and 0.3% ointment concentrations, respectively.[1,2] Interestingly, tacrolimus was absorbed regardless of occlusion at significantly higher rates in damaged skin, with percutaneous penetration of 40 ng/cm2 per hour. Thus, while on topical therapy, the patient’s skin will absorb progressively lower quantities of the agent as the lesions heal. This self-regulatory property of tacrolimus is a major advantage, as it should result in fewer adverse effects over the course of treatment.[4] In one randomized, double-blind study, a 3-week course of twice daily, topically applied tacrolimus ointment 0.03%, 0.1% and 0.3% resulted in blood concentrations below 0.25 ng/mL in most patients.[5] This low systemic absorption rate is typical of the majority of clinical cases. The mean time taken to attain the highest blood concentration of tacrolimus is between 5 and 6 h after application in adults and 2.5 h in children.[6] In another study, the bioavailability of topical tacrolimus was found to be lower than 0.5%. 6 Furthermore, tacrolimus does not seem to accumulate, either in the skin or blood, following repeated applications.[7] When taken orally, the absorption of tacrolimus is erratic and poor. The bioavailability of the drug ranges from 5% to 67%. 8 Intravenous administration of tacrolimus has resulted in the highest relative tissue concentrations in the spleen, lung and kidneys, followed by heart, skin and muscle, then fat and bone marrow and finally by liver, bone and blood.[9] During topical administration, there is no evidence of cutaneous metabolism. Systemically, tacrolimus metabolism is mediated by the cytochrome P450 3A4 isoenzyme. It is metabolized in the liver, by CYPIA and CYPIIIA.[8] In vitro studies have identified eight different metabolites. When SMS 201-995 is administered via the intraperitoneal route, the effects of tacrolimus are enhanced and thus may enable lower doses of the latter to be used.[10] When administered systemically, tacrolimus is eliminated in bile. It is cleared at 2.25 L/h, with a half-life of 40 h. 1 It has been found that paediatric transplant patients under 6 years old have higher weight-normalized clearance of tacrolimus, as compared with older children and adults.

Mode of action

Tacrolimus is a prodrug that enters the T cells and binds to immunophilins, forming a complex that binds competitively and blocks calmodulin.[2] This has the spin-off effect of not activating phosphatase calcineurin, which disables the dephosphorylation of NF-AT and subsequently inhibits entry of NF-AT into the nucleus, suppressing gene transcription. The final result is a decreased responsiveness of T cells to antigens. Tacrolimus can also exert a broad range of immunomodulatory effects on various skin disorders by binding to cell surface steroid receptors and inhibiting mast cell adhesion, inhibiting the release of mediators from mast cells and basophils, decreasing intercellular adhesion molecule-1 and E-selectin lesional blood vessel expression, and downregulating the expression of IL-8 receptor and Fcε RI on Langerhans cells.[11-13] Langerhans cells are considered to be important in the pathophysiology of many inflammatory diseases.[14] There is speculation that the features involved in the activation of Langerhans cells are common with T-cell activation; in other words, there is a dependence on calcineurin in the activation of Fcε RI-specific transcription factor.[15] Tacrolimus may downregulate the expression of FcεRI. Langerhans cells and other CD1a+ skin dendritic cells are important targets of tacrolimus.[14] It has also been suggested that tacrolimus is able to increase levels of p53.2 Topical tacrolimus has been shown to decrease cytokine mRNA levels of IL-1α, IL-1β and macrophage inflammatory protein (MIP)-2, which results in lymph node cell proliferation.16,17 Tacrolimus inhibits the transcription and release of cytokines, for example, IL-2, Il-3, IL-4, IL-5, interferon-γ, tumor necrosis factor-α, and granulocyte-monocyte colony stimulating factor.[18] Additionally, the production of T-helper 1 (Th1) and Th2 cytokines is inhibited by tacrolimus.[18]

Side effects

Owing to its potent activity as an immunosuppressant, tacrolimus has a number of adverse effects when administered orally or intravenously following transplant operations. Nephrotoxicity, represented by elevated creatinine, blood urea nitrogen, hyperkalaemia and reduction of the glomerular filtration rate, as well as vasoconstrictive effects, such as hypertension are among the most serious adverse effects.[19-22] There are also various neurotoxic adverse effects that can occur with systemic therapy. The major ones include mutism, aphasia, encephalopathy, seizures, psychosis, coma and focal disturbances. These reactions have an incidence of 5–10%. [23,24] Minor adverse effects such as headaches, transient, tremors, paraesthesias, photophobias, somnolence and insomnia occur in approximately 20% of individuals.[25,26] Systemic tacrolimus can also cause adverse reactions in the gastrointestinal system, causing diarrhoea, nausea, constipation, anorexia and vomiting. Respiratory disorders such as dyspnoea, pleural effusion and atelectasis, and cutaneous disorders, such as pruritus or a rash may develop. Other adverse effects include fever, pain, peripheral oedema, arthralgia and asthenia. Hypersensitivity reactions may also occur and may be due castor oil derivatives in the parenteral formulation.[24]

Indications

Tacrolimus is a macrolide lactone originally derived from Streptomyces tsukubaensis. Although structurally unrelated to cyclosporine, tacrolimus has a very similar mechanism of action; that is, it blocks the production of proinflammatory cytokines by T lymphocytes by inhibiting calcineurin.Tacrolimus, however, appears to be 10 to 100 times as potent as an immunosuppressive. Oral tacrolimus (FK506) is used for prevention of organ rejection in recipients of renal and hepatic transplants.

Manufacturing Process

The novel 17-allyl-1,14-dihydroxy-12-[2-(4-hydroxy-3-methoxycyclohexyl)-1- methylvinyl]-23,25-dimethoxy-13,19,21,27-tetramethyl-11,28-dioxa-4- azatrcyclo[22.3.1.04,9]octacos-18-ene-2,3,10,16-tetraone (FR-900506), substance can be produced by culturing a FR-900506 substance(s)-producing strain belonging to the genus Streptomyces (e.g. Streptomyces tsukubaensis No. 9993, FERM BP-927) in a nutrient medium.FermentationA culture medium (160 ml) containing glycerin (1%), corn starch (1%), glucose (0.5%), cottonseed meal (1%), dried yeast (0.5%), corn steep liquor (0.5%) and calcium carbonate (0.2%) (adjusted to pH 6.5) was poured into each of ten 500 ml-Erlenmeyer flasks and sterilized at 120°C for 30 min. A loopful of slant culture of Streptomyces tsukubaensis No. 9993 was inoculated to each of the medium and cultured at 30°C for 4 days on a rotary shaker. The resultant culture was inoculated to a medium containing soluble starch (5%), peanut powder (0.5%), dried yeast (0.5%), gluten meal (0.5%), calcium carbonate (0.1%) and Adekanol (deforming agent, Trade Mark, maker Asasi Denka Co.) (0.1%) (150 liters) in a 200-liter jar-fermentor, which had been sterilized at 120°C for 20 min in advance, and cultured at 30C for 4 days under aeration of 150 liters/minutes and agitation of 250 rpm.Isolation and PurificationThe cultured broth thus obtained was filtered with an aid of diatomaseous earth (5 kg). The mycelial cake was extracted with acetone (50 liters), yielding 50 liters of the extract. The acetone extract from mycelium and the filtrate (135 L) were combined and passed through a column of a non-ionic adsorption resin "Diaion HP-20" (Trade Mark, maker Mitsubishi Chemical Industries Ltd.) (10 L). After washing with water (30 L) and 50 % aqueous acetone (30 L), elution was carried out with 75 aqueous acetone. The eluate (30 liters) was evaporated under reduced pressure to give residual water (2 L). This residue was extracted with ethyl acetate (2 L) three times. The ethyl acetate extract was concentrated under reduced pressure to give an oily residue. The oily residue was mixed with twice weight of acidic silica gel (special silica gel grade 12, maker Fuji Devison Co.), and this mixture was slurried in ethyl acetate. After evaporating the solvent, the resultant dry powder was subjected to column chromatography of the same acidic silica gel (800 ml) which was packed with n-hexane. The column was developed with nhexane (3 L), a mixture of n-hexane and ethyl acetate (4:1 v/v, 3 L) and ethyl acetate (3 L). The fractions containing the object compound were collected and concentrated under reduced pressure to give an oily residue. The oily residue was dissolved in a mixture of n-hexane and ethyl acetate (1:1 v/v, 30 ml) and subjected to column chromatography of silica gel (maker Merck Co., Ltd. 230-400 mesh) (500 ml) packed with the same solvents system. Elution was carried out with a mixture of n-hexane and ethyl acetate (1:1 v/v, 2 liters and 1:2 v/v, 1.5 L) and ethyl acetate (1.5 L). Fractions containing the first object compound were collected and concentrated under reduced pressure to give crude FR-900506 substance (3 g) in the form of yellowish powder.This powder of the FR-900506 substance could be transformed into a form of white crystals by recrystallization thereof from acetonitrile. Melting point: 127°-129°C.

Therapeutic Function

Immunosuppressive

Biochem/physiol Actions

Product does not compete with ATP.

Veterinary Drugs and Treatments

Tacrolimus has recently been studied at the University of Tennessee College of Veterinary Medicine where investigators found it equally effective as cyclosporine and effective for cyclosporine-resistant cases of KCS. It exerts its effects through a mechanism similar to that of cyclosporine, however exact mechanisms of action in causing tear production are still being determined.

in vitro

tacrolimus (fk506) has been reported to inhibit the interleukin 2(il-2) production and the response of mixed lymphocyte culture. in addition, tacrolimus (fk506) added to the cell cultures has been revealed to inhibit murine or human mixed lymphocyte reactivity and the generation of cytotoxic t cells. furermor, tacrolimus (fk506) has also been reported to dose-dependently suppress the production of various cytokines including il-2, il-3, il-4, and γ-interferon, in response to different stimulis. besides, tacrolimus has shown its efficacy in the prevention of allograft rejection in animal transplant models. tacrolimus has been found to be significantly efficient in experimental hepatic allografts, and has hepatotrophic properties [1].

Drug interactions

Potentially hazardous interactions with other drugs Ciclosporin: may increase the half-life of ciclosporin and exacerbate any toxic effects. The two should not be prescribed concomitantly. Care should be taken when converting from ciclosporin to tacrolimus. Tacrolimus levels increased by: amlodipine, atazanavir, basiliximab, boceprevir, bromocriptine, chloramphenicol, cimetidine, cortisone, danazol, dapsone, diltiazem, ergotamine, ethinyloestradiol, felodipine, fosamprenavir, gestodene, grapefruit juice, imidazole and triazole antifungals, lidocaine, lansoprazole, possibly levofloxacin, macrolides, midazolam, nicardipine, nifedipine, norethisterone, omeprazole, pantoprazole, posaconazole, ranolazine; ritonavir, saquinavir, Chinese herbal remedies containing extracts of Schisandra sphenanthera, tamoxifen, theophylline, verapamil and voriconazole. Tacrolimus levels decreased by: carbamazepine, caspofungin, fosphenytoin, isoniazid, phenobarbital, phenytoin (fosphenytoin and phenytoin levels possibly increased), primidone, rifampicin, possibly rifabutin and St John’s wort. Increased nephrotoxicity with: aminoglycosides, amphotericin, NSAIDs, sulfamethoxazole, trimethoprim and vancomycin. Increased risk of hyperkalaemia with: potassiumsparing-diuretics and potassium salts. Anticoagulants: possibly increases concentration of dabigatran - avoid. Antipsychotics: avoid with droperidol, increased risk of ventricular arrhythmias. Antivirals: increased risk of nephrotoxicity with acyclovir, ganciclovir, valaciclovir and valganciclovir; concentration affected by efavirenz; concentration of both drugs increased with telaprevir; concomitant use with dasabuvir and ombitasvir/paritaprevir/ ritonavir is not recommended unless the benefits outweigh the risks, if used concomitantly, tacrolimus should not be administered on the day dasabuvir and ombitasvir/paritaprevir/ritonavir are initiated. Beginning the day after dasabuvir and ombitasvir/ paritaprevir/ritonavir are initiated; reinitiate tacrolimus at a reduced dose based on tacrolimus levels. The recommended tacrolimus dosing is 0.5 mg every 7 days, monitor levels at initiation and throughout treatment. Clotrimazole: more than doubles the bioavailability of tacrolimus (US-based researchers report that concomitant clotrimazole substantially increases the relative oral bioavailability of tacrolimus in renal transplant recipients. Inpharma. 2005 Dec 10; 1517: 15). Cytotoxics: concentration of afatinib possibly increased - separate dose by 6-12 hours; use crizotinib with caution; concentration increased by imatinib.

Metabolism

Tacrolimus is extensively bound to erythrocytes in the blood, and variations in red cell binding account for much of the variability in pharmacokinetics. It is extensively metabolised in the liver, mainly by cytochrome P450 isoenzyme CYP3A4, and excreted, primarily in bile, almost entirely as metabolites. Considerable metabolism also occurs in the intestinal wall.There are several metabolites identified. Only one of these has been shown in vitro to have immunosuppressive activity similar to that of tacrolimus. The other metabolites have only weak or no immunosuppressive activity. In systemic circulation only one of the inactive metabolites is present at low concentrations. Therefore, metabolites do not contribute to pharmacological activity of tacrolimus.

Overview

Tacrolimus (also FK-506 or Fujimycin) is an immunosuppressive drug whose main use is after organ transplant to reduce the activity of the patient's immune system and so the risk of organ rejection. It is also used in a topical preparation in the treatment of severe atopic dermatitis, severe refractory uveitis after bone marrow transplants, and the skin condition vitiligo. Tacrolimus was first extracted from the fermentation broth of Streptomyces tsukuba, a soil microbe found in Tsukuba, Japan.1 The name tacrolimus is derived by taking the ‘t’ for Tsukuba, the name of the mountain where the soil sample was extracted, ‘acrol’ for macrolide and ‘imus’ for immunosuppressant.[2] Although structurally unrelated to cyclosporin, tacrolimus shows a similar spectrum of immunosuppressive effects to this agent at the cellular and molecular level. Initial studies indicated that tacrolimus was a powerful immunosuppressant, displaying approximately 100-fold greater in vitro potency than cyclosporin in inhibiting T cell activation. Subsequent in vivo studies have shown tacrolimus to be effective both in suppressing spontaneous and experimental autoimmune disease, and in preventing allograft and xenograft rejection in animal models of organ transplantation. Initially, tacrolimus was used for systemic immunosuppression of patients who had undergone allograft transplants to stop them from rejecting their new grafts. Soon, however, through the benefit of the serendipity of science, it was noticed that tacrolimus could produce favorable results in skin disorders in some of the patients who had undergone transplantation. The discovery of tacrolimus has thus lead to greater understanding of skin pathology, for example of atopic dermatitis.[3] Subsequently, other topical applications of tacrolimus were reported and the use of this agent in dermatology is gradually expanding. Figure 1 The chemical structure of Tacrolimus

Definition

ChEBI: Tacrolimus is a macrolide containing a 23-membered lactone ring, originally isolated from the fermentation broth of a Japanese soil sample that contained the bacteria Streptomyces tsukubaensis.

Brand name

Prograf (Astellas); Protopic (Astellas).

General Description

Immunosuppressant that blocks T-cell proliferation in vitro by inhibiting the generation of several lymphokines, especially IL-2. Shown to inhibit the activity of FK-506 Binding Protein, thereby reversing its effects on sarcoplamic reticulum Ca2+ release. Shown to inhibit the Ca2+-dependent phosphatase, Calcineurin (Cat. No. 539565), as well as Na+-K+-ATPase in nephron segments. Also shown to inhibit aldosterone-induced synthesis of Giα-3 protein.
